Air Differential Pressure switches for air, ideal for use with gas interlock systems, they can also be used as positive pressure switches, vacuum sensors or differential pressure switches for air, flue gas and other non-aggressive gases. They monitor extremely slight pressure differences and trigger switch-on, switch-off or switch-over operations if a set value is reached. Fields of application include fan monitoring on calorific value boiler units or on atmospheric wall-mounted units with flue gas fan, fan monitoring and filter monitoring on intake and extract ventilation systems, on air-conditioning systems, in laboratories and in kitchens, frost-protection control on heat exchangers and closed-loop control of butterfly valves for air and fire dampers for instance.
The pneumatic and electrical connections are accessible from the same side in order to ensure space-saving installation.
Specification
Air Differential Pressure Switch Specification
24V-250V ac
Ambient temperature -20 to 85 C
5mm push-on connection
IP54
0.2 - 2 MBAR (20-200pa) - 0.1 mbar diff (10pa)
Features
Air Differential Pressure Switch Features
Monitoring of air, flue gas and other non-aggressive gases
High switching point stability
Switching point selection via hand wheel
Screw terminals or AMP plugs for electrical connections
Flexible mounting options
All connections accessible from one side
EC type-tested and certified
Supplied with 2 metres of clear hose and two spiots.
