The top-of-the-line Pro 86/88 burner - this is a 17mm pin-point burner that offers precision jewellery work, gold and silver forging, and soft soldering up to 10mm pipe with ease. Silver soldering gets up to around 615°C. The specs are 0.25kW, 20g/h at 2 bar. This burner connects with a M20 x 1 thread. You'll want to use it with the 3511 or 3509 neck tubes.
This 3938 is the most accurate burner in the Sievert Pro 86/88 range - and its a pin-point flame equivalent for the M20 x 1 thread system. Where the 8842 Lightline needlepoint burner uses the M8 x 0.75 thread via the 3501 adapter neck tube - the 3938 just hooks up to standard Pro 86/88 neck tubes (3511 or 3509) which makes it the perfect choice for Pro 86/88 users wanting some serious precision flame capability without needing that Lightline neck tube adapter.
This 17mm burner puts out a fine, short (38mm) pin-point flame at 0.25kW - same output and consumption as the 8842. Soft soldering gets you up to 400°C on pipe up to 10mm; and you can silver solder up around 615°C for all your gold and silver work.
Key Features & Benefits
Smallest Pin-Foint Flame in the Pro 86/88 Range - we are talking pin-point precision here, the most precise work the standard pro neck tube system can deliver.
Connects Directly into Pro 86/88 Neck Tubes - M20 x 1 thread so just fits the 3511 (70mm) and 3509 (180mm) neck tubes, no need for any adapter.
Silver Soldering to ~615°C - perfect for all your gold and silver jewellery work, silver soldering and precious metal applications.
Soft Soldering to 10mm Pipe - great for small component and pipe nipple soldering at minimum output.
0.25kW / 20g/h - lowest output and most economical in the Pro range.
Brass Construction - 38.21mm Body Length - nice and compact for getting in and around tight spaces.
Recommended Neck Tube: 3511 - the short 70mm neck tube is a must have for bench-level precision work with the 3938.
Soft soldering small components & pipe nipples to 10mm
Pro 86 (3486) & Pro 88 (3488) handle owners looking to upgrade to a precision flame on standard neck tubes
Upgrading from the 3939 fine burner for the absolute best possible flame on the Pro system
Got the finest pin-point flame on the standard Pro 86/88 neck tube system. Pop it in your shopping basket today and we will get it delivered to you right away. Neck tube (3511 recommended) and handle sold separately.
Specification
Sievert 3938 Pin-Point Gas Blow Torch Burner Specification
Brand
Sievert
Article Number
393802
Flame Type
Pin-point – finest flame in the Pro 86/88 range
Burner Diameter
17mm
Burner Body Length
38.21mm (47.64mm including thread)
Heat Output
0.25 kW at 2 bar
Working Pressure
2 bar
Gas Consumption
20 g/h at 2 bar
Soft Soldering Capability
Up to 400°C – max pipe diameter 10mm
Silver Soldering Capability
~615°C
Burner Connection
M20 × 1 – standard Pro 86/88 neck tube thread
Material
Brass
Compatible Neck Tubes
3511 (70mm, recommended) & 3509 (180mm)
Compatible Handles
Sievert Pro 86 (3486) & Pro 88 (3488)
Suitable Applications
Jewellery soldering, gold & silver work, small component soldering
Features
Sievert 3938 Pin-Point Gas Blow Torch Burner Features
Finest Flame in the Pro 86/88 Burner Range — Pin-point burner for the most precise work the standard Pro neck tube system can deliver.
Connects Directly to Pro 86/88 Neck Tubes — M20 × 1 thread — fits the 3511 (70mm) and 3509 (180mm) neck tubes directly, without requiring the Lightline 3501 adapter.
Silver Soldering to ~615°C — Suitable for gold and silver jewellery work, silver soldering and precious metal applications.
Soft Soldering to 10mm Pipe — For small component and pipe nipple soldering at very low output.
0.25kW / 20g/h — The lowest output and most economical burner in the Pro range.
Brass Construction — 38.21mm Body Length — Compact for precise close-up positioning.
Recommended Neck Tube: 3511 — The short 70mm neck tube is recommended for bench-level precision work with the 3938.
