Carry out installation and maintenance work on heating systems several times a day using the flue gas analyser with Longlife sensors. The EN 50379 testo 300 Longlife flue gas analyser is supplied with O2 and CO H2-compensated sensor up to 30,000 ppm (NO - can be retrofitted), modular flue gas probe, testo Bluetooth® printer, case and practical accessories.
Delivery Scope
testo 300 Longlife flue gas analyzer with O2 and CO H2-compensated sensor up to 30,000 ppm, NO - can be retrofitted (0633 3004 88)
USB mains unit, including cable (0554 1106)
Modular flue gas probe 180 mm, Ø 8 mm, Tmax. 500°C; TÜV tested and certified; 2.2 m hose (0600 9760)
Spare dirt filters for modular flue gas probe; 10 off (0554 3385)
BLUETOOTH®/IRDA printer, including 1 roll of thermal paper and rechargeable battery (0554 0621)
Spare thermal paper for printer, indelible ink (0554 0568)
Instrument case (height: 130 mm) for instrument, probes and accessories (0516 3300)
Please note that this product is made to order. Typical lead time may be 2-3 weeks. Please contact us to get a more exact delivery date.
Specification
Testo 300 LL Flue Gas Analyser Longlife Printer Kit Specification
Modular flue gas probe, 180 mm, Ø 8 mm, Tmax 500 °C, TÜV-tested
General technical data
Length probe shaft
180 mm
Cable length
2.2 m
Diameter probe shaft
8 mm
Product colour
Black
Temperature maximum
500 °C
Diameter
6 mm
Weight
524 g
Spare particle filter, 10 off
General technical data
Dimensions
height: 2.9 mm, ø: 29.7 mm
Product colour
white
Weight
12 g
Spare thermal paper for printer
General technical data
Dimensions
120 x 75 x 60 mm
Product colour
white
Weight
50 g
Product-/housing material
paper
Instrument case (height: 130 mm) - for instrument, probes and accessories
General technical data
Weight
3880 g
Dimensions
520 x 400 x 130 mm (LxWxH)
Product-/housing material
Plastic
Product colour
Black
testo EasyHeat v2.12 SP4 - PC software
General technical data
System requirements
Windows® 7; Windows® 8; Windows® 10
Features
Testo 300 LL Flue Gas Analyser Longlife Printer Kit Features
O2 sensor and H2-compensated CO sensor up to 30,000 ppm thanks to integrated fresh air dilution
NO sensor - can be retrofitted
Longer sensor service life thanks to automatic sensor protection
Integrated draught and gas zeroing without removing the probe – the flue gas probe can remain in the flue during zeroing
For intensive daily use: high-quality Longlife sensors for O2 and CO with a service life of up to 6 years. That means at least one sensor replacement is saved in the course of a normal working life
Compliance with EN 50379, Parts 1-3
Integrated fine pressure and 4 Pa measurement for legally prescribed measurements
Manufacturer's warranty of up to 5 years on O2 and CO sensor with product registration – without a maintenance contract
Versatile probes and fast probe changes: take advantage of quick-change probes and the multi-functional handle for attaching a variety of probe shafts (each available to order separately). You can, for instance, use longer probe shafts for flue gas pipes with larger diameters or flexible probes for difficult-to-access measuring points
Optionally available probes and accessories for further measuring tasks, such as gas flow pressure measurement, gas pipe testing, differential temperature measurement and ambient CO measurement
Smart-touch display for intuitive operation of the flue gas analyser: the display responds without delay – just as easy as on your smartphone
Get the measurement result faster: clearly structured measurement menus for all relevant measurements
Create documentation (including measuring value, measuring location, customer data) easily on site
Save PDF measurement reports directly in the instrument and always have them available
Signature function: your customer can sign measurement reports directly on the instrument
E-mail measurement reports directly to the office or customers via WLAN (hotspot)
Large 5-inch HD display – enables you to see all the system's parameters immediately
Testo interface function for direct data transfer of measuring values to industry/customer-specific software*
Ready to use straight away: in standby mode, the testo 300 is ready to measure at the touch of a button. Use it straight away with the next customer – because you no longer need to wait for the end of the zeroing phase
Integrated Bluetooth® interface: immediate printout of the measuring values on-site with the appropriate printer
10-hour rechargeable battery life: an average measurement period of 2 hours means the flue gas analyser is capable of being used for one week
Integrated, extra-strong magnets for easy fixing during the measuring process
