Description

Pegler Yorkshire VSH XPress 42mm x 1.1/4" Water Female Connector (38101)

A female connector lets you join copper tube to a threaded part without a flame. The Pegler Yorkshire VSH XPress S2 is a copper fitting with a 42mm press end on one side and a 1.1/4" BSP parallel female thread (Rp 1.1/4") on the other, for connecting 42mm copper tube to a threaded fitting, valve or appliance connection.

It’s BSI Kitemark approved to BS 8537:2010 and WRAS approved. It’s for hot and cold water services, vented and unvented closed circuit heating and chilled water, and rated to 16 bar across a temperature range of -24°C to 110°C. The Leak Before Press feature means an unpressed fitting shows up during pressure testing. The press end is M-profile jaw compatible, for use with half-hard and hard copper tube to BS EN 1057 R250 and R290, and it carries Pegler’s 25-year manufacturer’s guarantee (conditions apply).

The thread is a Bsp parallel female thread, so check the mating thread and the sealing method for the part you’re connecting, following that part’s manufacturer’s instructions. The joint on the press end needs no flame, though site rules still apply. This fitting is for water and heating, and isn’t for gas: Pegler has a separate XPress Gas range.

Key Features & Benefits
  • 42mm Press x 1.1/4" BSP Parallel Female: Joins copper tube to a threaded part (Rp 1.1/4").
  • Heat-Free Press-Fit: No flame is needed to make the press joint.
  • BSI Kitemark (BS 8537:2010) and WRAS Approved: Plus DVGW and OVGW (water), per Pegler.
  • Leak Before Press: Unpressed fittings are identified during pressure testing.
  • 16 Bar, -24°C to 110°C: Pressure rating across the temperature range.
  • M-Profile Jaw Compatible: For use with R250 and R290 copper tube.
  • 25-Year Manufacturer's Guarantee: Conditions apply.
Ideal For
  • Connecting 42mm copper tube to a 1.1/4" threaded valve, tap tail or appliance connection.
  • Hot and cold water services and closed circuit heating.
  • Installers who want a heat-free press joint on copper tube.
Why Buy This Product?

For connecting 42mm copper tube to a 1.1/4" threaded part without soldering, this Kitemarked, WRAS-approved press-fit female connector is made for the job. Leak Before Press shows unpressed fittings when you test.

Order the Pegler Yorkshire VSH XPress 42mm x 1.1/4" Water Female Connector online today.

Specification

Pegler VSH Xpress Water Female Coupling - 42mm x 1.1/4" BSP FM Specification

Brand Pegler Yorkshire
Product Code 38101 (S2)
Product Type XPress Straight Female Connector
Size 42mm Press x 1.1/4" BSP Parallel Female
Material Copper
Approvals BSI Kitemark (BS 8537:2010); WRAS; DVGW; OVGW (Water)
For Use With BS EN 1057 R250 / R290 Copper Tube
Connection Press (M Profile) x BSP Parallel Female Thread
Maximum Pressure 16 bar
Temperature Range -24°C to 110°C at 16 bar
Guarantee 25 Years (Conditions Apply)
Suitable Applications Hot and Cold Water, Vented and Unvented Closed Circuit Heating, Chilled Water
Not Suitable For Gas (Use XPress Gas Range)
Features

Pegler VSH Xpress Water Female Coupling - 42mm x 1.1/4" BSP FM Features

  • 42mm Press x 1.1/4" BSP Parallel Female: Joins copper tube to a threaded part
  • Heat-Free Press-Fit: No flame is needed to make the press joint.
  • BSI Kitemark (BS 8537:2010) and WRAS Approved: Plus DVGW and OVGW (water), per Pegler.
  • Leak Before Press: Unpressed fittings are identified during pressure testing.
  • 16 Bar, -24°C to 110°C: Pressure rating across the temperature range.
  • M-Profile Jaw Compatible: For use with R250 and R290 copper tube.
  • 25-Year Manufacturer's Guarantee: Conditions apply.
