Brass Reduced End Compression Tee – 22mm x 15mm x 22mm
Taking a smaller branch off a larger main run is a common requirement in mixed-size pipework, and this tee does it in one fitting. It connects two 22mm pipes in line with a 15mm branch at 90° using mechanical compression joints, so no soldering or heat is needed.
Made from brass and manufactured to BS EN 1254-2, it's WRAS approved and suitable for hot and cold water, heating circuits, compressed air, and low-pressure gas distribution. It's rated to 1 bar at 30°C for gas, 7 bar at 30°C for compressed air, and up to 25 bar (size dependent) for water between 0°C and 95°C, and works with copper, stainless steel, low carbon steel, and select plastic pipe (with inserts).
Key Features & Benefits
22mm x 15mm x 22mm Reduced Tee: Takes a 15mm branch off a 22mm run in one fitting.
Flame-Free Installation: No soldering or welding required, ideal for heat-restricted areas.
WRAS Approved: Safe for use in drinking water systems in the UK.
Durable Brass Construction: Corrosion resistant and built to last.
Leak-Free Mechanical Joint: The compression seal grips without heat or adhesives.
Manufactured to BS EN 1254-2: Made for consistency and compliance.
Ideal For
Domestic and commercial plumbing (hot and cold water).
Central heating installations.
Low-pressure gas and compressed air systems.
Pipe rerouting in tight or hard-to-reach areas.
Why Buy This Product?
Taking a 15mm branch off a 22mm main with a single reduced tee means one joint instead of a straight tee plus a separate reducer, which is one fewer connection point where a leak could develop. A flame-free joint also means no hot works permit and no fire risk, and WRAS approval and BS EN 1254-2 compliance make it a fitting you can specify with confidence across water, heating, and low-pressure gas work.
Order the Brass Reduced End Compression Tee – 22mm x 15mm x 22mm online today.
Specification
Brass Reduced End Compression Tee – 22mm x 15mm x 22mm Specification
