Pegler VSH Xpress Water Female Adaptor - 28mm x 3/4" BSP FM
You might also like:
Connecting 28mm copper tube to a 3/4" male threaded fitting without a flame is what this press-fit female adaptor is for. The Pegler Yorkshire VSH XPress Water Female Adaptor has a plain 28mm copper end that is inserted into an XPress fitting and pressed there, and a 3/4" BSP parallel female thread that connects to a 3/4" BSP male threaded component such as a valve, tap or other threaded outlet. It is a water-range XPress fitting, for use on hot and cold water services and on vented and unvented closed circuit heating and chilled water applications.
The fitting is BSI Kitemark approved to BS 8537:2010 and is WRAS and Kiwa approved. The XPress fitting it is inserted into is for use with copper tube to BS EN 1057 R250 and R290 and M-profile press jaws, and the 25-year Pegler guarantee applies when the system is built with copper tube to BS EN 1057 (conditions apply).
The fitting is rated at 16 bar from -20°C to 110°C. Don’t use water-range XPress fittings on gas. For gas pipework use the XPress Gas range, which has its own approvals and lower pressure limits. Seal the threaded connection with a thread sealant suitable for the application, press every joint and test the system as part of your installation process.
For a 28mm copper to 3/4" BSP female connection on a water system, this XPress adaptor gives you a heat-free press joint with a Kitemark and a 16 bar rating. If you are not sure you need a 3/4" BSP parallel female thread, contact our team before you order.
Order the Pegler Yorkshire VSH XPress 28mm x 3/4" BSP Female Water Adaptor online today.
| Brand | Pegler Yorkshire XPress |
|---|---|
| Product Code | 38166 |
| Product Type | XPress Water Female Adaptor (Copper End x BSP Parallel Female) |
| Size | 28mm x 3/4" BSP Parallel Female |
| Equal/Reducing | Adapting |
| Material | Copper |
| Approvals | WRAS, Kiwa, BSI Kitemark (BS 8537:2010) |
| For Use With | BS EN 1057 R250 / R290 Copper Tube |
| Connection | Plain Copper End (For Insertion Into an XPress Fitting) x BSP Parallel Female |
| Media | Water Only, Not for Gas |
| Maximum Operating Pressure | 16 bar |
| Temperature Range | -20°C to 110°C |
| Guarantee | 25 Years With BS EN 1057 Copper Tube (Conditions Apply) |
| Suitable Applications | Hot & Cold Water Services; Vented & Unvented Closed Circuit Heating; Chilled Water |
