The 20" Galvanised Overbraided LPG Pigtail – NR Butane Nut W20 is a top-notch high-pressure hose designed to provide safe, long-lasting and efficient connections for Propane (LPG) cylinders. Made right here in the UK by the folks at Hamilton Gas Products, this pigtail is built to last in one of the most advanced LPG hose facilities in Europe and meets the tough EN 16436-1 Class 3 standards, plus its also Calor Gas Approved, so you can have complete peace of mind.
This pigtail features a tough rodent-proof galvanised multi-braid overbraiding, ideal for protecting it from physical damage – great for caravans, motorhomes, home cylinder installations and even commercial LPG systems. The built-in non-return/excess flow valve will kick in and automatically restrict gas flow if there is a rupture or sudden surge, which is a real lifesaver.
With a 20" length for maximum reach and a 5-year warranty, you can rely on this rugged pigtail to keep going even in the toughest of environments.
This pigtail offers industry standard protection, Calor-approved safety, plus a non-return valve, so it is probably one of the most long-lasting pigtails out there. From caravans to commercial LPG systems, it will give you long-term reliability, top level safety and consistent performance every time.
Give your LPG setup a serious upgrade today – get your hands the 20" Galvanised Overbraided NR Pigtail now and have the best, most durable and safest pigtail available!
| Brand | Hamilton Gas Products |
|---|---|
| Product Type | LPG Pigtail Assembly |
| Braiding | Braided (Galvanised) |
| Standard (Tested to) & Approvals | EN 16436-1 Class 3 – Calor Gas Approved |
| Burst Pressure | 90 bar |
| Colour | Black with orange strip |
| Connection | N/R Butane Nut (Irish F-Valve) x W20 Nut + Tail |
| Gas Type | Propane |
| Inside Diameter | 6.3mm |
| Length | 20" |
| N/R or ST | N/R (Non-return) |
| Operating Pressure | Working Pressure: 30 bar |
| Outside Diameter | 16.3mm |
| Compatible Cylinders | UK – Calor Gas 4.5kg; Ireland – Calor Gas & Flo-Gas 10.89kg, 19kg, 34kg & 47kg |
| Suitable Applications | Manual and auto changeover regulators and wall blocks |
| Warranty | 5 Years under normal use |
