Ensure the safe and efficient transportation of natural gas and LPG with our high-quality Yellow MDPE Gas Pipe. This 63mm x 50m coil is BSI approved and Kitemarked to GIS/PL2-2:2006 standards, providing reliable performance and peace of mind for your gas distribution projects.
Key Features:
BSI Approved & Kitemarked: Complies with GIS/PL2-2:2006 standards, ensuring top-notch quality and safety.
Durable Material: Made from Medium Density Polyethylene (MDPE), offering excellent durability and flexibility.
Standard Dimensional Ratio: SDR 11, providing a balanced wall thickness for optimal performance.
Pressure Rating: Maximum pressure rating of 5.5 bar at 20°C, suitable for a wide range of applications.
Versatile Use: Ideal for both Natural Gas and LPG distribution, making it a versatile choice for various projects.
Coil Design: Supplied in a 50m coil, making it easy to transport and install in various settings.
Application: Suitable for Natural Gas and LPG
Safety Note:
This pipe is held in a coil under tension and is securely strapped. Please refer to the provided guidance notes on handling PE pipe supplied in coils before attempting to release the pipe.
Specification
Yellow MDPE Gas Pipe - 63mm x 50m Coil Specification
Brand
Radius
Product Type
MDPE Gas Pipe
Standards
GIS PL2-2, EN 1555-2
Material
Polyethylene
Colour
Yellow
Inside Diameter
50.8mm
Outside Diameter
63mm
Max Pressure
5.5 bar at 0 to 20°C
Pipe Length
50m
Weight
51.8 kg
Suitable Applications
Natural Gas and LPG
Features
Yellow MDPE Gas Pipe - 63mm x 50m Coil Features
BSI Approved & Kitemarked: Meets GIS/PL2-2:2006 standards for assured quality and safety.
High-Quality Material: Constructed from durable Medium Density Polyethylene (MDPE) for excellent longevity.
Standard Dimensional Ratio: SDR 11, providing optimal wall thickness and performance.
Pressure Rating: Handles a maximum pressure of 5.5 bar at 20°C, suitable for various applications.
Versatile Use: Suitable for both Natural Gas and LPG distribution.
Convenient Coil Design: Comes in a 63mm diameter, 50m long coil for easy transportation and installation.
Safety Note: Coiled under tension and strapped securely; follow handling guidelines to ensure safety.
Temperature Tolerance: Maintains integrity and performance at standard operating temperatures.
Reliable Performance: Ensures safe and efficient transportation of gases.
Ease of Installation: Flexible and manageable, making it ideal for various gas distribution projects.
