Tesla T-Bar Expansion Vessel Fixing Bar Kit (T-BARKIT)
Where floor space is tight, a T-bar fixing kit gives a genuine alternative to standing an expansion vessel on the floor, mounting it securely off a wall bracket instead. The Tesla T-BARKIT covers vessels from 2 to 25 litres, and bundles together the wall bracket, service valve, safety valve and manual air vent needed for a complete, self-contained installation.
The kit's manifold connects to the expansion vessel via a 3/4" BSP union, with a 15mm compression x 1/2" BSP male adaptor on the system side. A built-in 3 bar safety relief valve with integrated pressure gauge protects against overpressure, and the expansion vessel service valve allows the vessel to be isolated for servicing or replacement without draining down the wider system.
Key Features & Benefits
All-in-One Fixing Kit: Includes wall bracket, service valve, safety valve and fittings for quick installation.
Space-Saving Design: Perfect for tight spaces where vessel floor-mounting is not possible.
Reliable Safety Valve: Built-in 3 bar pressure relief valve with gauge protects the system from overpressure.
Integrated Service Valve: Allows for easy isolation of the expansion vessel for maintenance or replacement.
Manual Air Vent Included: Removes trapped air for optimal system performance.
Strong Construction: Bracket supports vessels up to 25L (subject to wall and fixing strength).
Ideal For
Wall-mounting expansion vessels from 2–25 litres.
Domestic sealed central heating systems.
Compact or space-limited plant rooms.
Service-friendly boiler or cylinder installations.
Kit Contents
Wall mounting bracket (bar) with arm (280mm).
Expansion vessel service valve (3/4" BSP union).
Manual air vent.
3 bar safety relief valve with pressure gauge.
15mm compression x 1/2" BSP male system adaptor.
Why Buy This Product?
Bringing bracket, service valve, safety valve and air vent together as one kit removes the need to source and fit each component separately, and the dedicated service valve means a vessel can be isolated and swapped without draining the whole system. A 280mm arm gives useful reach off the wall, keeping the vessel accessible for future servicing rather than tucked awkwardly against the surface.
Order the Tesla T-Bar Expansion Vessel Fixing Bar Kit online today.
Specification
Tesla T-Bar Expansion Vessel Fixing Bar Kit Specification
Manufacturer
Tesla
Product Code
T-BARKIT
Product Type
Expansion Vessel Fixing Kit
Application
Sealed System Expansion Vessel Fixing Bar
Suitable Vessel Sizes
2 – 25 Litres (Wall & Fixings Dependent)
Bracket Dimensions
Bracket: H 110 x 55mm; Arm 280mm Long
System Connection
15mm Compression x 1/2" BSP Male
Vessel Connection
3/4" BSP
Pressure Relief Valve
3 Bar with Integrated Gauge
Includes
Service Valve, Air Vent, Safety Valve, Bracket, Fittings
Mounting
Wall-Mounted
Features
Tesla T-Bar Expansion Vessel Fixing Bar Kit Features
All-in-One Fixing Kit: Includes wall bracket, service valve, safety valve and fittings for quick installation.
Space-Saving Design: Perfect for tight spaces where vessel floor-mounting is not possible.
Reliable Safety Valve: Built-in 3 bar pressure relief valve with gauge protects the system from overpressure.
Integrated Service Valve: Allows for easy isolation of the expansion vessel for maintenance or replacement.
Manual Air Vent Included: Removes trapped air for optimal system performance.
Strong Construction: Bracket supports vessels up to 25L (subject to wall and fixing strength).
