The Clesse APS2000 1st Stage Ajustable OPSO Fixed 1 bar (1-3bar) Gas Regulator with Schrader TP is also adjustable between 1–3bar should it be necessary.
These are mainly used on Commercial, Industrial and Agricultural LPG Installations using Bulk Tanks.
They provide the first stage regulation function and are fitted directly onto the Tanks or inline using Tank Manifold kits, and have OPSO (Over Pressure Shut Off) Device fitted before or after the regulator. This regulator has the OPSO fitted before the regulator and is monitored upstream via a sensing line.
Design and performance to BS EN 13785
Specification
Clesse APS2000 1st Stage Ajustable OPSO 1 bar Gas Regulator - 120kg/hr Specification
Brand
Clesse
Standards
BS EN 13785
Capacity
120 kg/h
Inlet
3/4" Bsp female
Outlet
3/4" Bsp female
Operating Pressure
1 bar (Adjustable)
OPSO
Yes
UPSO
No
Inlet Pressure
1 to 16 bar
Pressure Release Valve
No
Pressure Test Point
No
Stage
First Stage High Pressure
Suitable Application
Propane bulk tank installations
Guarantee
2 Years
Product Type
1st Stage Propane Tank Regulators
Features
Clesse APS2000 1st Stage Ajustable OPSO 1 bar Gas Regulator - 120kg/hr Features
Adjustable & Fixed Pressure: The Clesse APS2000 comes factory set at 1bar but allows adjustments between 0.5 – 3 bar for tailored LPG system management.
Ideal for Heavy-Duty Use: Specifically designed for commercial, industrial, and agricultural settings, this regulator excels in installations using bulk tanks.
First-Stage Regulation: Offers critical first-stage regulation, ensuring efficient gas flow when mounted directly onto tanks or configured inline with Tank Manifold kits.
Enhanced Safety with OPSO: Equipped with an Over Pressure Shut Off (OPSO) device, strategically installed before the regulator for superior safety, and monitored via an upstream sensing line.
Weather-Adaptive Performance: Features a pressure compensation system for consistent operation under various weather and inlet conditions, ensuring stability.
Comprehensive Design Standards: Engineered to meet BS EN 13785 standards, the APS2000 regulator promises reliable design and performance.
Integrated Pressure Test Point: Comes standard with a Schrader TP for easy pressure monitoring and maintenance checks.
Versatile OPSO Installation: Available with OPSO positioned either upstream or downstream, offering flexible safety options tailored to your system’s needs.
Inbuilt Filter System: New models now include a filter system to protect against foreign matter, ensuring long-term reliability and optimal operation.
